Lifted Toyota Tundra: Your Options
A lift gives a Tundra more ground clearance, room for bigger tires and a taller stance. Toyota now offers its own 3-inch TRD lift, and our parts department can fit it or help you choose. Here is what to know before you raise a truck.
Quick answer
The cleanest way to a lifted Tundra is Toyota's own hardware: for 2026 the TRD 3-inch Lift Kit is offered with the Tow Tech Package on the Tundra TRD Rally Package, engineered for the truck's suspension, electronics and the tow rating. Genuine TRD accessories installed by a Toyota dealer are covered by Toyota's accessory warranty. Aftermarket lifts range from a leveling kit to several inches of suspension lift; they change handling, speedometer accuracy and towing behavior, and any damage they cause is not covered by the new vehicle warranty.
Toyota's TRD lift
For the 2026 model year Toyota added a TRD 3-inch Lift Kit and Tow Tech Package to the Tundra TRD Rally Package. Because it is a Toyota part, it is designed around the truck's geometry, the stability control calibration and the standard tow hitch and 7/4-pin connector now fitted to every Tundra. If you want a lifted truck with a factory feel and factory support, that is the one to ask about. Contact our parts department about availability for your Tundra.
Lift types compared
| Option | Height | What it does | Things to weigh |
|---|---|---|---|
| Leveling kit | About 1 to 2 inches, front only | Raises the nose to match the rear; room for a slightly larger tire | Least change to handling; little effect on towing |
| TRD 3-inch Lift Kit (Toyota) | 3 inches | Full suspension lift matched to the truck | Offered on the 2026 TRD Rally Package; dealer-installed accessory warranty |
| Aftermarket suspension lift | 2 to 6 inches | Longer springs or struts, new control arms on taller kits | Alignment, driveline angles and the tow rating change; warranty claims on related parts can be refused |
| Body lift | 1 to 3 inches | Spacers between body and frame; bigger tires without suspension changes | No extra suspension travel; bumpers and gaps need attention |
What changes when you lift
- Tires: a lift is usually the first step to a larger tire. Larger tires change the speedometer and odometer reading and the gearing feel; the TPMS and calibration need to follow.
- Alignment: every suspension lift needs a full alignment, and some need new control arms to get camber back in range.
- Towing: ride height changes the hitch height and the truck's behavior under load. Toyota rates the 2026 Tundra at up to 12,000 pounds properly equipped; a lifted truck may need a drop hitch and a trailer brake controller check.
- Driver assistance: cameras and radar for Toyota Safety Sense are aimed for the stock ride height. A dealer-installed TRD lift accounts for that; aftermarket lifts may need recalibration.
- Warranty: Toyota's new vehicle warranty does not cover damage caused by non-Toyota parts. Genuine accessories installed at delivery carry Toyota's accessory warranty.
The 2026 Tundra underneath
| Engine | Output | Notes |
|---|---|---|
| i-FORCE 3.4L twin-turbo V6 | 389 hp, 479 lb-ft | 10-speed automatic; standard on most grades |
| i-FORCE MAX 3.4L twin-turbo V6 hybrid | 437 net combined hp, 583 lb-ft at 2,400 rpm | 10-speed automatic; standard on TRD Pro and Capstone |
Maximum towing 12,000 pounds when properly equipped. New for 2026: a 32.2-gallon tank on every grade, standard tow hitch and connector, and the TRD 3-inch lift option on TRD Rally. The TRD Pro gets Multi-Terrain Select, Crawl Control, a locking rear differential and optional ISO Dynamic seats.
Or buy one already built
The Tundra TRD Pro is the factory off-road truck, and the TRD Off-Road Package adds the same electronic aids to other grades. Browse Tundra inventory for TRD Pro, TRD Rally and TRD Off-Road trucks in stock, or ask us to order one with the TRD lift.
Frequently asked questions
Does Toyota make a lift kit for the Tundra?
Yes. For 2026 Toyota offers a TRD 3-inch Lift Kit with the Tow Tech Package on the Tundra TRD Rally Package.
Will a lift kit void my Tundra warranty?
A genuine TRD lift installed by a Toyota dealer is covered by Toyota's accessory warranty. An aftermarket lift does not void the whole warranty, but damage it causes to related parts is not covered.
How much can a 2026 Tundra tow?
Up to 12,000 pounds when properly equipped. A lift changes hitch height and handling under load, so set the trailer up for the new ride height.
What is the biggest tire I can fit on a lifted Tundra?
It depends on the lift, the wheel offset and the grade. Our parts team can check fitment for your truck.
Build your Tundra with Elgin Toyota
Our parts and service teams fit genuine TRD accessories and can quote the TRD lift, wheels and tires together.
Sources
Checked against Toyota's 2026 Tundra announcement and owner resources on October 14, 2026. Confirm accessory availability and warranty terms for your truck with our parts department.
- 2026 Toyota Tundra: A Bold New Chapter in Full-Size Pickup Excellence (July 22, 2025), Toyota USA Newsroom
- Toyota owner's manuals and Warranty & Maintenance Guides, Toyota Motor Sales, U.S.A.
